ultraspy classes

Probe classes

class ultraspy.probes.probe.Probe(config)

Probe class to handle the probe configuration.

Variables:

  • name (str) – The name of the probe

  • geometry_type (str) – The type of the probe (either linear, convex or matricial). Is defined by child

  • central_freq (float) – The central frequency of the probe (in Hz)

  • bandwidth (float) – The bandwidth of the probe (should be between 0 and 200%), in %

  • geometry (numpy.ndarray) – The coordinates of the elements of the probe

  • nb_elements (int) – The number elements

Initialization for the Probe.

Parameters:

config (dict) – The dictionary with the parameters needed to build a probe, at the minimum the central_freq and the nb_elements

get_thetas()

This should return the thetas of each probe element if they exist. When it happens, this needs to be overwritten in the dedicated child class (see ConvexProbe for example).

Returns:

The list of thetas for the probe, if called here and not from child (convex), returns a list of 0 thetas

Return type:

numpy.ndarray

set_bandwidth(bandwidth)

Setter for the bandwidth.

Parameters:

bandwidth (float) – The new bandwidth

set_central_freq(central_freq)

Setter for the central freq.

Parameters:

central_freq (float) – The new central frequency

show()

Shows the probe geometry.

show_delays(delays, sound_speed=1540)

Shows the delays per transmissions using this probe.

Parameters:

  • delays (numpy.ndarray) – The delays of each sequence (nb_t, nb_e)

  • sound_speed (float) – The speed of sound used for the delays

show_sequences(emission_sequences, reception_sequences)

Shows the emission / reception sequences for this probe, per transmission.

Parameters:

  • emission_sequences (numpy.ndarray) – The indices, per transmission of the probe elements used for emission

  • reception_sequences (numpy.ndarray) – The indices, per transmission of the probe elements used for reception

class ultraspy.probes.linear_probe.LinearProbe(config)

LinearProbe class to handle the linear probes parameters.

Variables:

  • name (str) – The name of the probe

  • geometry_type (str) – The type of the probe, linear here

  • central_freq (float) – The central frequency of the probe (in Hz)

  • bandwidth (float) – The bandwidth of the probe (should be between 0 and 200%), in %

  • geometry (numpy.ndarray) – The coordinates of the elements of the probe

  • nb_elements (int) – The number elements

Parent initializer, then read the config info to generate the linear geometry.

Parameters:

config (dict) – The dictionary with the central_freq, the nb_elements and, either the x/y/z coordinates, or the pitch

Scan classes

class ultraspy.scan.Scan(on_gpu)

The parent class, whatever the format of scan you’re willing to beamform, it must inherit from this class to guarantee that its main methods will exist. See the GridScan and PolarScan below for examples.

Variables:

  • on_gpu (bool) – If set to False, the points will be stored in numpy arrays. Else case, cupy.array

  • is_3d (bool) – Defines if the scan is in 3 dimensions or not

  • pixels (tuple) – The coordinates of the pixels to beamform, either a 2D tuple with the coordinates (xx, zz), or 3D (xx, yy, zz)

  • nb_x (int) – The resolution in the lateral axis

  • nb_y (int) – The resolution in the elevational axis

  • nb_z (int) – The resolution in the axial axis

  • axial_step (float, numpy.ndarray) – The step of the axial dimension, it is either a float if the resolution is the same through the whole grid, or an array if it changes based on the lateral / elevational position. In this case, the output has the shape (nb_x,) for 2D, or (nb_x, nb_y) for 3D scans

  • shape (tuple) – The shape of the scan: (nb_x, nb_z) in 2D, or (nb_x, nb_y, nb_y) in 3D

Initialization for the Scan, should not be called from here. Use a child class instead.

Parameters:

on_gpu (bool) – If set to False, the points will be stored in numpy arrays. Else case, cupy.array

property axial_step

Returns the axial step, should be implemented in child classes.

build_pixels()

Builds the pixels coordinates, based on the scan characteristics, this should be implemented in child classes.

downsample_axial(*args, **kwargs)

Down-samples the scan in the axial direction, this should be implemented in child classes.

property nb_x

Returns the lateral resolution, should be implemented in child classes.

property nb_y

Returns the elevational resolution, should be implemented in child classes.

property nb_z

Returns the axial resolution, should be implemented in child classes.

oversample_axial(*args, **kwargs)

Over-samples the scan in the axial direction, this should be implemented in child classes.

ravel_pixels()

Ravels the pixels of the scan, to make them usable for beamforming. The returned pixels are always a 3D tuple, with the elevational coordinates of the pixels set to zero if we are in 2D.

Returns:

The ravelled pixels coordinates (coords_x, coords_y, coords_z)

Return type:

tuple

remove_fixed_axis()

Remove the fixed axis information, if any.

set_on_gpu(on_gpu)

Updates the on_gpu attribute if requested, will change the format of the pixels coordinates.

Parameters:

on_gpu (bool) – True if is on GPU

property shape

Returns the shape of the scan, in 2D or 3D based on the scan characteristics.

Returns:

The shape of the scan: (nb_x, nb_z) in 2D, or (nb_x, nb_y, nb_y) in 3D

Return type:

tuple

class ultraspy.scan.GridScan(axis_1, axis_2, axis_3=None, on_gpu=True)

GridScan class to handle a regular grid of pixels. It expects either two or three vectors (for 3D), with respectively the x, y, and z coordinates.

Variables:

  • on_gpu (bool) – If set to False, the points will be stored in numpy arrays. Else case, cupy.array

  • is_3d (bool) – Defines if the scan is in 3 dimensions or not

  • pixels (tuple) – The coordinates of the pixels to beamform, either a 2D tuple with the coordinates (xx, zz), or 3D (xx, yy, zz)

  • nb_x (int) – The resolution in the lateral axis

  • nb_y (int) – The resolution in the elevational axis

  • nb_z (int) – The resolution in the axial axis

  • axial_step (float) – The step of the axial dimension

  • shape (tuple) – The shape of the scan: (nb_x, nb_z) in 2D, or (nb_x, nb_y, nb_y) in 3D

Initialization for the Grid scan, it expects either two or three vectors (for 3D). If two are given, the grid will be 2D (lateral / axial). Else case, the grid will also include the y coordinates ( lateral / elevational / axial).

Parameters:

  • axis_1 (np.ndarray) – The first axis for the grid, always the lateral axis

  • axis_2 (np.ndarray) – The second axis for the grid, if axis_3 is provided, this will be the elevational axis, else case, it will be used as the axial axis

  • axis_3 (np.ndarray) – Optional, if provided, the axis_2 is used as the elevational and this one as the axial, for 3D grids

  • on_gpu (bool) – If set to False, the points will be stored in numpy arrays. Else case, cupy.array

property axial_step

Returns the axial step.

build_pixels()

Builds the pixels coordinates, this is simply a meshgrid with the two or three vectors provided at initialization, based on if the grid is 2D or 3D.

Returns:

The pixels coordinates (xx, zz) in 2D or (xx, yy, zz) in 3D

Return type:

tuple

downsample_axial(factor)

Down-samples the scan in the axial direction by a factor.

Parameters:

factor (int) – The factor for the down-sampling, will be rounded if not an integer

fix_an_axis(axis, index)

If on 3D, defines a fixed axis for slice beamforming (especially for tri-plan or 2D visualization).

Parameters:

  • axis (int) – The axis to fix, either 0, 1 or 2, for the x, y or z axes

  • index (int, float) – The index of the vector to fix

property nb_x

Returns the lateral resolution.

property nb_y

Returns the elevational resolution (None if 2D).

property nb_z

Returns the axial resolution.

oversample_axial(factor)

Over-samples the scan in the axial direction by a factor.

Parameters:

factor (int) – The factor for the oversampling, will be rounded if not an integer

Reader class

class ultraspy.io.reader.Reader(data_file, system='ultraspy', verbose=True)

Reader class to handle the data files from different ultrasound systems. After initialization, it has three attributes: the data itself, the data_info, and the probe class, which can be used directly in the Beamformer class. Check their getters to learn more about them. You also can call Reader.available_systems to have the list of the implemented ultrasound systems.

Currently, the supported systems are:

  • ultraspy: reads data formatted for the ultraspy library

  • picmus: reads data issued from the PICMUS challenge ( creatis.insa-lyon.fr/Challenge/IEEE_IUS_2016)

  • must: reads the rotating disk data from MUST (biomecardio.com/MUST)

  • simus: data generated using the simulation tool SIMUS (biomecardio), contained RF and param

  • simu_3d: reads simulated 3d data from FieldII

  • dbsas: reads the data saved with the PA2 system of the company DB-SAS. It also works with the PAMini with some adaptations of the way it saves data

  • vera: reads data saved by the verasonics Vantage system, the saved workspace needs to have some specific variables (RcvData, Trans, Receive, Resource, PRF and P. It hasn’t been tested in many situations, so for now, you should assume it’ll only work on plane-waves emissions, with regular parameters

  • ulaop: reads data saved by the UlaOp system (from the MSD lab). This one is very high level and has been proven not to work in some situations (those should be checked some day). It should work fine on plane wave emissions (no focus) though.

Variables:

  • available_systems (list) – The list of the available systems

  • data (dict) – The data, of shape (nb_frames, nb_plane_waves, nb_elements, nb_time_samples). The number of elements can be 1D or 2D when we are using a 3D probe

  • data_info (dict) – The information about the data

  • acquisition_info (dict) – The information about the acquisition setup

  • probe (dict) – The probe class

It initializes the Reader class, using a given data file, known for being recorded using a given system.

Parameters:

  • data_file (str) – The path where to find the data

  • system (str) – The name of the system to use, default is the data formatted for this library

  • verbose (bool) – If True, we print a recap of the loaded data and of what has been extracted

get_acquisition_info()

Returns the information related to the acquisition, which contains:

  • sampling_freq: in Hz

  • t0: in s

  • prf: in Hz

  • signal_duration: in s

  • delays: in m/s

  • sound_speed: in m/s

Returns:

The information about the acquisition

Return type:

dict

get_data()

Returns the extracted data (of shape: (nb_frames, nb_transmissions, nb_elements, nb_time_samples))

Returns:

The Numpy array with the ultrasound data

Return type:

numpy.ndarray

get_data_info()

Returns the information related to the data, which contains:

  • data_shape: tuple of int

  • data_type: the type of the data

  • is_iq: bool

Returns:

The information about the data

Return type:

dict

get_probe()

Returns the probe class, which contains (mainly):

  • geometry: of shape (nb_dim, nb_elements)

  • central_freq: in Hz

  • bandwidth: in percentage

Returns:

The information about the probe

Return type:

Probe
